Dell PowerEdge XE9680 GPU Server

Dell PowerEdge XE9680 GPU Server

  • 6U 8-way GPU server

  • Two 4th Gen Intel® Xeon® Scalable processor with up to 56 cores per processor

  • 8 NVIDIA H100 700W SXM5 for extreme performance or 8 NVIDIA A100 500W SXM4 GPUs, fully interconnected with NVIDIA NVLink technology

  • Up to 10x16 Gen5 PCIe full-height, half-length

  • Host multi-tenant environments using virtualization options like NVIDIA Multi-Instance GPU (MIG) capability

  • NVIDIA AI software

Request Info

Features

Experience Extreme Acceleration For AI

Rapidly develop, train and deploy machine learning models with this high-performance application server made for artificial intelligence, machine learning and deep learning.

No compromise AI infrastructure

Turbocharge your application performance with Dells PowerEdge XE9680 8-way GPU 6U servers, designed to drive the latest cutting-edge AI, Machine Learning and Deep Learning Neural Network applications.

  • Combined with high core count of up to 56 cores in the new generation of Intel Xeon processors and the most GPU memory and bandwidth available today to break through the bounds of today's and tomorrow's AI computing.
  • Choose between 8 NVIDIA H100 700W SXM5 for extreme performance or 8 NVIDIA A100 500W SXM4 GPUs for a balance of performance and power, fully interconnected with NVIDIA NVLink technology
  • Improve training performance with up to 900GB/s bandwidth for GPU-GPU communication, 1.5x more than the previous generation.
  • Host multi-tenant environments using virtualization options like NVIDIA Multi-Instance GPU (MIG) capability

Cyber Resilient Architecture

Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations.

Increase efficiency with an autonomous infrastructure

The Dell OpenManage systems management portfolio delivers a secure, efficient, and comprehensive solution for PowerEdge servers. Simplify, automate and centralize one-to-many management with the OpenManage Enterprise console and iDRAC

Tech Specs & Customization

Processor
Processor
Two 4th Generation Intel® Xeon® Scalable processors with up to 56 cores per processor
Operating System
Operating System
Canonical® Ubuntu® Server LTS
Red Hat® Enterprise Linux
Bezel
Bezel
Optional LCD bezel or security bezel
Dimensions & Weight
Height
10.36 inches (263.2 mm)
Width*
18.97 inches (482.0 mm)
Depth*
39.71 inches (1008.77 mm) with bezel
39.17 inches (995 mm) without bezel
Weight
235.89 lbs. (107 kg)
Memory*
DIMM Speed
Up to 4800 MT/s
Memory Type
RDIMM
Memory Module Slots
32 DDR5 DIMM slots
Maximum RAM
RDIMM 4 TB max
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC Restful API with Redfish
iDRAC Service Module
Consoles
CloudIQ for PowerEdge plug in
OpenManage Enterprise
OpenManage Enterprise
OpenManage Enterprise Integration for VMware® vCenter
OpenManage Integration for Microsoft® System Center
OpenManage Integration with Windows Admin Center
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin
Tools
Dell System Update
Dell Repository Manager
Enterprise Catalogs
iDRAC RESTful API with Redfish
IPMI
RACADM CLI
OpenManage Integrations
BMC Truesight
Microsoft® System Center
OpenManage Integration with ServiceNow
RedHat® Ansible® Modules
Terraform Providers
VMware® vCenter and vRealize Operations Manager
Storage Controllers
Internal Boot
Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs
Software RAID: S160
Accelerators
Accelerators
8 NVIDIA HGX H100 80GB 700W SXM5 GPUs or
8 NVIDIA HGX A100 80GB 500W SXM4 GPUs,
fully interconnected with NVIDIA NVLink technology
Storage
Front Bays
Up to 8 x 2.5-inch NVMe SSD drives max 122.88 TB
Power Supplies
Power Supplies
2800W Titanium 200-240 VAC or 240 VDC redundant, hot swap

Cooling
Fans
Up to 6 High performance (HPR) gold grade fans installed
in mid tray
Up to 10 High performance (HPR) gold grade fans installed
on the rear of the system
All are hot swap fans
Slots
PCie
Up to 10 x16 Gen5 (x16 PCIe) full-height, half-length
Form Factor
Form Factor
6U Rack Server
Ports
Network Options
1 x OCP 3.0 (optional)
2 x 1GbE LOM (optional)
Front Ports
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0
1 x VGA
Rear Ports
1 x USB 2.0
1 x USB 3.0
1 x VGA
1 x RJ45 iDRAC9 ethernet port
Internal Ports
1 x USB 3.0
