Dell PowerEdge R7715 Server

Dell PowerEdge R7715 Server

  • 2U GPU server

  • One 5th Generation AMD EPYC 9005 Series processors with up to 160 cores per processor

  • Up to 3x 450W DW GPUs; Up to 6x 75W SW GPUs

  • 24 DDR5 DIMM slots, supports RDIMM 6 TB max, speeds up to 5200 MT/s

  • 12 x 3.5-inch SAS/SATA or other configurations

  • Ideal for virtualization, hyper-converged infrastructure

Request Info

Features

Versatility meets performance

  • 5th generation AMD EPYC processor can deliver up to two-times better performance compared to previous generations
  • Deliver more memory density with DDR5 (up to 6TB of RAM) memory capacity
  • Improve responsiveness or reduce app load time for power users with up to 3x 450W DW GPUs, or 6x 75W SW GPUs

Built-in security

PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.

Accelerate AI Innovations

Dell PowerEdge servers are designed specifically for AI-ready infrastructure, serving as the foundation for faster business transformation, deeper insights with Generative AI, and accelerated AI/ML/DL operations.

Tech Specs & Customization

Processor
Processor
One 5th Generation AMD EPYC 9005 Series processor with up to 160 cores per processor
Operating System
Operating System
Canonical Ubuntu Server LTS
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
VMware ESXi
SUSE Linux Enterprise Server
Bezel
Bezel
Optional metal bezel
Dimensions
Height
3.41 inches (86.8 mm)
Width*
18.97 inches (482.0 mm)
Depth*
31.59 inches (802.4 mm) with bezel
31.55 inches (801.51 mm) without bezel
Memory*
Memory Type
Supports registered ECC DDR5 DIMMs only
Memory Module Slots
24 DDR5 DIMM slots, supports RDIMM 6 TB max,
speeds up to 5200 MT/s
GPU
GPU Options
Up to 3x 450W DW; Up to 6x 75W SW
Management
Embedded / At-the-Server
iDRAC 10
iDRAC Direct
iDRAC Restful API with Redfish
Racadm CLI
Quick Sync 2 wireless module
Storage Controllers
Internal Controllers
(RAID): PERC H365i,H965i, H975i
Internal Boot
Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS)
External HBAs
(non-RAID): HBA465e
Storage
Front Bays
2 x U.2
12 x 3.5-inch SAS/SATA
8 x 2.5 Universal/ 16 x 2.5-inch SAS/SATA /
  24 x 2.5-inch SAS/SATA
16 x 2.5-inchSAS/SATA SSD + 8 x U.2 NVMe drives
8 x EDSFF E3.S / 16 x EDSFF E3.S / 32 x EDSFF E3.S /
  40 x EDSFF E3.S
Power Supplies
Power Supplies
Platinum 800W, 1100W
Titanium: 800W, 1100W, 1500W, 1500W 277Vac & HVDC, 1800W*, 2400W, 3200W, 3200W 277Vac & HVDC
Telco: 1400W -48VDC
Cooling
Fans
Up to six hot plug fans
Cooling options
Air cooling, Direct Liquid Cooling (DLC)
Slots
PCie
Up to eight PCIe slots (x16 connectors):
Slot 1: 1 x16 Gen5 Full Height
Slot 2: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length
Slot 3: 1 x16 Gen5 Full Height or Low Profile
Slot 4: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length
  or 1 x16 OCP3.0
Slot 5: 1 x16 Gen5 Full Height
Slot 7: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length
Slot 8: 1 x16 Gen5 Full Height
Slot 9: 1 x16 Gen5 Full Height or Low Profile
Form Factor
Form Factor
2U Rack Server
Ports
Front Ports
1 x USB 2.0 Type-A (optional LCP KVM)
1 x USB 2.0 Type-C (HOST/BMC Direct)
1 x Mini DisplayPort (optional LCP KVM)
Rear Ports
1 x 1 Gb Dedicated BMC Ethernet port
2 x USB 3.1 Type-A
1 x VGA
