4U TRITON® Server

Intel Xeon®

4U TRITON® Server

  • 8 hot-swappable system nodes

  • Dual socket Intel® Xeon® Scalable processors

  • Significantly faster processing time

  • AI/ML — Significant reduction in training time

  • High Performance Computing (HPC) - Faster data processing

  • Blockchain — Acceleration of cryptocurrency mining

Simplify Sustainability With Liquid Immersion Cooling

  • Compact form factor
  • Vertically stackable configurations available
  • Simplified maintenance
  • Local and remote management interfaces
  • DCIM API-integration with monitoring tools
  • Zero waste of water

Technical Specification

Processor (per node)
CPU
Dual Socket Intel Xeon Scalable processors
Cores
Up to 32C/64T; Up to 48MB Cache
On-Board Devices (per node)
Chipset
Intel® C621A
Network
1x 1GbE RJ45
Operating Temperature Range
10°C to 35°C
Memory (per node)
System Memory
  • Memory Capacity: 16 DIMM slots
  • Up to 2TB: 8x 128 GB DRAM
  • Up to 4TB: 8x 512 GB PMem
Drive Bays (per node)
Hot-Swap
  • 6x 2.5" hot-swap NVMe/SATA/SAS drive bays
  • 6x 2.5" 7mm drive bays
Expansion Slots (per node)
PCI-Express
  • PCI-E 4.0 x8LP
Weight & Dimension
Weight
  • Net Weight: 150 lbs (68.04 kg)
  • Gross Weight: 200 lbs (90.71 kg)
Height
6.96" (177mm)
Width
17.63" (448mm)
Length / Depth
29" (737mm)

Want to learn more about the ASA Triton ® Server provided by ASA Computers?
